GS-02

GS-02 Balustrade System has designed for safety and infinite vision. It can be used easily in both interior and exterior places.

You can watch the product’s installation video here.

GLASS HEIGHT= H	THICKNESS ( mm )	L	TEST VALUES ( kN )
0 – 599 mm	( 5 + 1,52 + 5 ) , ( 6 + 1,52 + 6 )	1150 mm
0 – 599 mm	( 8 + 1,52 + 8 ) , ( 10 + 1,52 + 10 )	1250 mm
600 – 899 mm	( 5 + 1,52 + 5 ) , ( 6 + 1,52 + 6 )	1100 mm
600 – 899 mm	( 8 + 1,52 + 8 ) , ( 10 + 1,52 + 10 )	1200 mm
900 – 1099 mm	( 5 + 1,52 + 5 ) , ( 6 + 1,52 + 6 )	1000 mm
900 – 1099 mm	( 8 + 1,52 + 8 ) , ( 10 + 1,52 + 10 )	1100 mm
1100 – 1200 mm	( 5 + 1,52 + 5 ) , ( 6 + 1,52 + 6 )	900 mm
1100 – 1200 mm	( 8 + 1,52 + 8 ) , ( 10 + 1,52 + 10 )	1000 mm
GS-02 THE GLASS MEASURES FOR THIS SYSTEM ARE ON THE TABLE ABOVE. * ACCORDING TO HEIGHT OF THE BUILDING, GLASS HEIGHT AND THICKNESS MAY BE VARY.*
